Humanoid Detection Ai Defog Security WDR IP Poe CCTV Network H. 265 Onvif IP66 Bullet Camera
Features:
Waterproof IR Bullet Camera Water Resistance: IP66
IR LED: ¢5X24pcs, IR Range: 25M
Video Output: 1 x RJ45 port, wifi Optional
Support Onvif, Support Gmail/GOOGLE/QQ/EMAIL
PNP(Plug and Play), support smart phone & tablets
OSD, Motion Detection, Remote View and Control, IR-Cut
Working Temperature: -10ºC~ +60ºC
Size: 55mm x 85mm x 80mm
Weight:600g
Specifications
Waterproof IR Bullet Camera Water Resistance: IP66
IR LED: ¢5X24pcs, IR Range: 25M
Video Output: 1 x RJ45 port, wifi Optional
Support Onvif, Support Gmail/GOOGLE/QQ/EMAIL
PNP(Plug and Play), support smart phone & tablets
OSD, Motion Detection, Remote View and Control, IR-Cut
Working Temperature: -10ºC~ +60ºC
Size: 55mm x 85mm x 80mm
Weight:600g
Specifications
| Model ID | SVN-WUB20L | SVN-WUB20T | SVN-WUB30C | SVN-WUB30X | SVN-WUB50C | SVN-WUB50M | SVN-WUB50X | SVN-WUB80 |
| Description | Waterproof IR Bullet IP Camera,Water Resistance: IP66, IR LED: ¢5X24pcs, IR Range: 25M | |||||||
| TV System | NTSC / PAL | |||||||
| Video Output | 1 x RJ45 port | |||||||
| Chipset Solution |
1/2.8" 2.0 MP CMOS Low illumination F37 + XM530 |
1/2.8" 2.0 MP CMOS Starlight Low illumination SONY IMX307 + HI3516EV200 |
1/2.7" 3.0 MP CMOS Low illumination SC4239 + Hi3516EV200 |
1/2.7" 4.0 MP CMOS Low illumination SC3335 + XM535 |
1/3" 5.0 MP CMOS Low illumination SC5335 + XM550 |
1/3" 5.0 MP CMOS Low illumination SONY IMX335 + XM550 |
1/3" 5.0 MP CMOS Low illumination SONY IMX335 + HI3516EV300 |
1/2" CMOS 4K Low illumination SC8238 + Hi3516AV200 |
| Resolution | 1080P@25fps, 720P@25fps | 1080P@25fps, 720P@25fps | 3MP@20fps, 1080P@25fps | 4MP@20fps, 3MP/1080P@25fps | 5MP@15fps, 3MP/1080P@25fps | 5MP@15fps, 3MP/1080P@25fps | 5MP@20fps, 3MP/1080P@25fps |
8MP@15fps, 5mp@25fps |
| Effective Pixels | 1920(H)×1080(V) | 1920(H)×1080(V) | 2048(H)×1536(V) | 2048(H)×1536(V) | 2560(H)×1920(V) | 2560(H)×1920(V) | 2560(H)×1920(V) | 3264(H)×2488(V) |
| Minimum Illumination | 0.001Lux | |||||||
| Lens | 3.6mm Board Lens/2.8mm ( Optional ) | 4mm(8M Pixels) | ||||||
| Sync,System | Internal Synchronization | |||||||
| Network | 1 RJ45 Ethernet interface, 10/100M adaptation | |||||||
| Video Compression | H.265 compression | |||||||
| Protocol | Support Gmail/GOOGLE/QQ/EMAIL | |||||||
| Onvif | Support Onvif | |||||||
| AI WDR | YES | NO | NO | YES | NO | YES | NO | YES |
| AI Defog | YES | NO | NO | YES | YES | YES | NO | YES |
| AI humanoid Detection | YES | NO | NO | YES | YES | YES | NO | YES |
| S/N Ratio | ≥ 58dB | |||||||
| POE | Optional(Externial POE) | |||||||
| WIFI | NO | |||||||
| Power Source | DC 12V/2A | |||||||
| Consumption | <5W | |||||||
| Operating Enviroment | -10ºC~60ºC / 10% ~ 95%RH | |||||||
| Working Humidity | ≤90% | |||||||
| Size(mm) | 55mm x 85mm x 80mm | |||||||
| Weight(kg) | 0.6 KG | |||||||
