4MP Dual Lens Camera with 165° panorama
Product features

  • 4MP (3840*1080)  HD resolution, the image is clear and delicate;
  • Dual-lens horizontal 165°wide-angle monitoring field of view, 32:9screen;
  • Support real time picture-in-picture
  • Support wired or wireless network connection
  • Support infrared&floodlight, support humanoid, intelligent (Alert Zone& Alert Line etc.);
  • Support 2D/3D noise reduction, digital wide dynamic;
  • 6 dot matrix infrared light and 6 dot matrix floodlight light; infrared night vision 30 meters, floodlight full color 20 meters;
  • Support 2.4G/5G wireless, 3dBi antenna, wireless transmission 30 meters;
  • Built-in TF card slot, maximum support 128G; support cloud storage;
  • Advanced Smart H.264 video compression technology, ultra-low bit rate, high-definition image quality;
  • Lightning protection, international standard IEC61000-4-5;
  • Support mobile phone/tablet remote viewing (iOS, android, Harmony OS);
  • Support a variety of cloud technologies, realize network penetration, push alarm information to mobile phones and other functions;
Technical parameters

Model WH604-F1BG
Display
Image Sensor Dual senser, 1/2.9" Progressive Scan CMOS
Video Resolution 2K; 3840*1080
Effective Pixels 4MP
Aspect Ratio 32 : 9
Video Encoding Smart H.264
Video Frame Rate Up to 15Fps
Video Bit Rate Up to 1024
Minimum Illumination 0Lux(IR ON)
Lens
Number of lenses 2 pcs
Focal Length 3.6MM
Field of view Horizontal field of view 155° ± 10°, vertical field of view 55° ± 10°
Lens Mount M12
Aperture Type Fixed Aperture
Maximum Aperture F1.4
Fill Light
Infrared Light 6pcs 18mil IR LEDs
Infrared Night Vision Screen Black and White
Night Vision Distance 10-30m
Floodlight 6pcs 18mil White Light
Floodlight Night Vision Color
Night Vision Distance 15-20m
Audio Intercom
Recording sound distance 15m
Intercom Distance 15m
Video Storage
TF Card Slot Maximum support 128G
Cloud Storage Support
Language
APP Language Chinese/English/Japanese/Portuguese
Voice Broadcast Chinese/English/Japanese/Portuguese
Terminal Equipment
Mobile Phone Support Android/Apple/Harmony system mobile phones
Laptop Support Android/Apple/Harmony system tablet
Desktop PC Not support
Smart Function
Motion Detection Support
Humanoid Detection Support
Vehicle Detection Support
Pet Identification Support
Linkage Alarm Mobile Phone Push Support
Linkage Device Voice Alarm Support
Signal Transmission
Transmission Type Wireless/Wired
Wired Interface 1 RJ45 10M/100M adaptive Ethernet port
Radio Frequency 2.4Ghz/5Ghz
Wireless Distance Unobstructed 30 meters, partition wall 10-15 meters
Packaging Specifications
Unit Size 171*152*95mm
Net Weight 0.58kg
30pieces/CTN 360*480*520MM
Carton Weight 18kg
