Counter-Uav

3km Detection Distance Counter-Uav-Radar

3D mechanical scanning radar, Multi group Sum beam Difference beam.
Improves the "low small slow" target detection capability while reducing the radar's transmit power at the same discovery distance.
Distinguish between ground and air targets.
Can work around the clock in harsh environments.
Multi-point operating frequency, using the same-frequency interference suppression technology to avoid co-channel interference.

Model	Rada-01B
Overview
Wave band	Ku
Process technology	chirp
Scan method	Azimuth machine scan+Euler frequency scan
Weight	≤18kg
Size	570×375×210(mm)
Power consumption	≤160W
Basic detection performance
Display range	0.075~20km
Azimuth angle	0°-360° scan
Euler angles	0°-40°
Measurement dimension	Distance / Azimuth angle / Euler angles / Speed
Detection distance
Mini UAV (RCS=0.01m²)	3Km
Detection accuracy
Distance accuracy	≤8m
Azimuth accuracy	≤0.8°
Euler accuracy	≤0.6°
Resolving power
Detection Resolving power	≤20m
Azimuth Resolving power	≤2.5°
Euler Resolving power	≤5°
Data process capacity
Track method	TWS / continuous track
Number of track targets	No less than 200
Map data	Stackable map
