33X AHD/CVI/TVI/CVBS 2MP IR High Speed Dome
Key Features
1/2.8" Sony IMX307 Progressive Scan CMOS
33x Optical Zoom
1920 (H) x 1080 (V)@25fps/30fps
Color:0.1lux,B/W:0.01lux
Day&Night and auto ICR function
360°continuous pan, -0°to~ +90° tilt
254 presets, Preset accuracy ±0.1°
Pan/Tilt speed H: 0.1-220°/s, V: 0.1-120°/s
5Sequence,1 Pattern
8 High-Power LED ARRAY lights,Night IR Distance:120m
IP66,All-aluminum enclosure , 3000V lightning protection, surge protection
Working temperature: -20°C ~+60°C.
Technical parameters
1/2.8" Sony IMX307 Progressive Scan CMOS
33x Optical Zoom
1920 (H) x 1080 (V)@25fps/30fps
Color:0.1lux,B/W:0.01lux
Day&Night and auto ICR function
360°continuous pan, -0°to~ +90° tilt
254 presets, Preset accuracy ±0.1°
Pan/Tilt speed H: 0.1-220°/s, V: 0.1-120°/s
5Sequence,1 Pattern
8 High-Power LED ARRAY lights,Night IR Distance:120m
IP66,All-aluminum enclosure , 3000V lightning protection, surge protection
Working temperature: -20°C ~+60°C.
Technical parameters
| Name | 33x 2MP AHD/CVI/TVI/CV BS PTZ IR Dome Camera |
| Model | SV-33CL82P5-TAC |
| Lens | |
| Optical Zoom | 33x Optical Zoom |
| Focal lenght | 33X f=4.6mm～152mm |
| Number aperture | F1.6(Wide)～CLOSE |
| Horizontal viewing angle | 66.1°（W）～2.46°（T） |
| Camera | |
| Image sensor | 1/2.8" Sony IMX307 Progressive Scan CMOS |
| Signal System | PAL / NTSC |
| Resolution |
1920 (H) x 1080 (V)/25fps 1920 (H) x 1080 (V)/30fps |
| Video frame | 25fps/30fps |
| Min.Illumination | Color:0.1lux,B/W:0.01lux |
| Exposure mode | Auto Exposure / Aperture Priority / Shutter Priority / Manual Exposure |
| IR-CUT | Day & Night ICR double filter auto switch |
| Focus | Auto/Manual |
| Output Video Format | AHD/CVI/TVI/CVBS 1080P-PAL/NTSC |
| PTZ Function | |
| IR LED | 8 High-Power LED ARRAY lights |
| Night IR Distance | 120M |
| Pan Range | 0°~ 360° Continuous pan |
| Tilt Range | 0°-90°Vertical，180°Auto flip |
| Speed (H) | 0.1°~ 22°/s |
| Speed (V) | 0.1°~ 120°/s |
| Preset Speed | 200°/s |
| Presets | 254 Presets |
| Sequences | 5 Sequences(Each 16 preset points) |
| Pattern | 1 pattern |
| Outage memory | Support |
| Watch function | Support |
| Proportion match | Support |
| General | |
| Operating Temp. | -20°C ~+60°C |
| Humidity | 10~80% RH( Non-condensing ) |
| Protection grade | IP66,All-aluminum enclosure , 3000V lightning protection, surge protection |
| Power | DC12V/5A |
