33X Opticol Zoom 1080P 800m Laser Network Vehicle/on Board IP PTZ Security Camera
Key Features
1080P 1/2.8" Progressive Scan CMOS;
33X(F5.5-180mm) optical zoom;
Laser distance:800m
Weatherproof IP66/67;
Synchronization zoom, enabling focus precisely adjusting the light intensity
ONVIF comply;
ideal for mobile surveillance, for vehicle, marine application
Application
Enclosed with aluminum housing and excellent sealing solution, the camera is designed with an ingress protection rating of IP66/67, protecting the internal components from dust, dirt and liquids.
The rugged, mobile mounting options make this camera ideal choice for many mobile surveillance
application:like law enforcement, vehicle surveillance, specialized robot, marine surveillance.
Technical parameters
| Model | |
| Model No. | SVN-33X800L |
| Visible Camera | |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Effective pixel | 1920*1080,2MP |
| Min. Illumination | Color:0.001 Lux @(F1.5,AGC ON); Black:0.0005Lux @(F1.5,AGC ON); IR ON:0Lux |
| White balance | Auto white balance, auto gain, auto exposure |
| Gain control | automatic / manual |
| Signal to noise ratio | ≥55dBG |
| BLC | On / off |
| Shutter | 1/3-1/100,000sec; Support slow shutter |
| Focus mode | automatic / manual |
| WDR | Super wide dynamic, automatic wide dynamic, 0-100 digital adjustment |
| DNR | 3D-DNR |
| Focal length | 5.5-180mm,33X option Zoom |
| Day/Night Switch | Dual Filter Switching Synchronized Image, Auto, Color, B&W, Timing, Threshold Control, Flip |
| Pan/Tilt | |
| 3D intelligent positioning | Support |
| Pan Range | 360° (endless) |
| Pan Speed | 0.05°/s ~ 80°/s |
| Tilt Range | -30° ~ +40° (or -20° ~ +90°) |
| Tilt Speed | 0.05° ~ 60°/s |
| Scale zoom | Support |
| Preset | 255 |
| Cruise scan | 6, each of which can add 18 preset points, and the residence time can be set |
| Power off memory | Support |
| Control | support RS485 and network control |
| Video output | support network HD and analog video output |
| Network | |
| Network interface | RJ45 10Base-T/100Base-TX |
| Image | 1920*1080 |
| Frame rate | 60fps |
| Video Compression | H.256/H.264 |
| Network Protocol | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G) |
| Video stream | Three bit stream |
| Local storage | Support Micro SD/SDHC/SDXC Card (128G) off-network local storage |
| Security | Password protection, multi-user access control |
| Laser distance | 800M |
| General | |
| Power | DC 10V-24V, wide voltage input; Power consumption: 36w |
| Working temperature | -40ºC~65ºC |
| Working humidity | <90% |
| Ingress Protection | IP67, 4000V Lightning protection, surge protection |
