Night vision: Full Color/Smart/Infrared Night Vision;

2MP(1920*1080) Resolution, 3.6MM + 8MM

Audio: Support voice intercom;

Connection method: Support AP/wifi/ cable connection three ways to connect;

APP: Support mobile phone APP(iOS, Android) monitoring remote monitoring, APP:CamHipro;

Storage management: support local TF card storage, the maximum can support 128G;

AI:Humanoid tracing, intrusion alarm;

Protocol: support ONVIF;

Technical parameters

Model No.	PTZ-DOY2-2DHN200WSC
Camera
Resolution	2MP(1920*1080)
Image sensor	T31N+SC2335+SC2335
Focal length	3.6MM+8MM
Night vision distance	Color: 20 meters, IR: 30 meters
Compression standard
Video compression standard	h.264/H.265
Video compression bit rate	32Kpbs-8Mpbs
Audio compression algorithm
Function
Audio input and output	Built-in pickup and speaker
Memory card	Support 8G-128G TF card
Standard	Support TCP/IP, HTTP, UDP, SMTP, DNS, DDNS, NTP and other protocols
Subtitle overlay	Support channel name, date and time, superimposed subtitles user can customize
Motion Detection	4 independent zones can be set
Communication Interface	1 RJ45 10M Ethernet port
Wifi
Wireless standard	IEEE802.11b/g/n
Frequency Range	2.4 GHz - 2.4835 GHz
Channel bandwidth	20/40MHZ
Safety	WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmission distance	20 meters (without obstacles)
AP (Hot Spot)	Support
General
Power	8W
Operating temperature	-10℃-55℃
Pan&Tilt
Control speed	Horizontal speed: 0.01°～15°/S, vertical speed : 0.01°～10°/S
Rotation range	Horizontal rotation: 180° ; Vertical 0°～90°,Automatic flip.
Track	Humanoid tracking
Installation method	hoisting, wall mounting
Power supply	DC12V
Size and weight
Package size	235*195*140MM
Product weight	About 0.9kg/set (including power supply)
Batch packing size	725*485*405MM (20pcs / box)
