4MP 3840*1080 Dual Lens Camera with 165° Panorama
Product Features
- 4MP (3840*1080) HD resolution, the image is clear and delicate;
- Dual-lens horizontal 165°wide-angle monitoring field of view, 32:9screen;
- Support real time picture-in-picture
- Support wired or wireless network connection
- Support infrared&floodlight, support humanoid, intelligent (Alert Zone& Alert Line etc.);
- Support 2D/3D noise reduction, digital wide dynamic;
- 6 dot matrix infrared light and 6 dot matrix floodlight light; infrared night vision 30 meters, floodlight full color 20 meters;
- Support 2.4G/5G wireless, 3dBi antenna, wireless transmission 30 meters;
- Built-in TF card slot, maximum support 128G; support cloud storage;
- Advanced Smart H.264 video compression technology, ultra-low bit rate, high-definition image quality;
- Lightning protection, international standard IEC61000-4-5;
- Support mobile phone/tablet remote viewing (iOS, android, Harmony OS);
- Support a variety of cloud technologies, realize network penetration, push alarm information to mobile phones and other functions;
| Model | WH604-F1BG |
| Display | |
| Image Sensor | Dual senser, 1/2.9" Progressive Scan CMOS |
| Video Resolution | 2K; 3840*1080 |
| Effective Pixels | 4MP |
| Aspect Ratio | 32 : 9 |
| Video Encoding | Smart H.264 |
| Video Frame Rate | Up to 15Fps |
| Video Bit Rate | Up to 1024 |
| Minimum Illumination | 0Lux(IR ON) |
| Lens | |
| Number of lenses | 2 pcs |
| Focal Length | 3.6MM |
| Field of view | Horizontal field of view 155° ± 10°, vertical field of view 55° ± 10° |
| Lens Mount | M12 |
| Aperture Type | Fixed Aperture |
| Maximum Aperture | F1.4 |
| Fill Light | |
| Infrared Light | 6pcs 18mil IR LEDs |
| Infrared Night Vision Screen | Black and White |
| Night Vision Distance | 10-30m |
| Floodlight | 6pcs 18mil White Light |
| Floodlight Night Vision | Color |
| Night Vision Distance | 15-20m |
| Audio Intercom | |
| Recording sound distance | 15m |
| Intercom Distance | 15m |
| Video Storage | |
| TF Card Slot | Maximum support 128G |
| Cloud Storage | Support |
| Language | |
| APP Language | Chinese/English/Japanese/Portuguese |
| Voice Broadcast | Chinese/English/Japanese/Portuguese |
| Terminal Equipment | |
| Mobile Phone | Support Android/Apple/Harmony system mobile phones |
| Laptop | Support Android/Apple/Harmony system tablet |
| Desktop PC | Not support |
| Smart Function | |
| Motion Detection | Support |
| Humanoid Detection | Support |
| Vehicle Detection | Support |
| Pet Identification | Support |
| Linkage Alarm Mobile Phone Push | Support |
| Linkage Device Voice Alarm | Support |
| Signal Transmission | |
| Transmission Type | Wireless/Wired |
| Wired Interface | 1 RJ45 10M/100M adaptive Ethernet port |
| Radio Frequency | 2.4Ghz/5Ghz |
| Wireless Distance | Unobstructed 30 meters, partition wall 10-15 meters |
| Packaging Specifications | |
| Unit Size | 171*152*95mm |
| Net Weight | 0.58kg |
| 30pieces/CTN | 360*480*520MM |
| Carton Weight | 18kg |
